四层框架结构食品公司办公楼设计☆
来源:wenku163.com 资料编号:WK1634284 资料等级:★★★★★ %E8%B5%84%E6%96%99%E7%BC%96%E5%8F%B7%EF%BC%9AWK1634284
资料介绍
摘要
旺旺食品公司办公楼,该建筑为四层,采用钢筋混凝土框架结构。
毕业设计主要流程是确定建筑设计方案、建筑设计、结构设计及后期整理。为了能更好的完成毕业设计我查阅了相关设计规范及主要参考资料。
设计过程包括建筑设计部分和结构设计部分。建筑设计根据办公楼的使用要求、自然条件、建筑造型及建筑艺术和室内布置等各方面进行平面布置和空间组织。结构设计部分根据毕业设计的要求,包括结构选型、结构布置、结构计算、施工图的绘制、构造要求的了解等。
关键词 办公楼 , 建筑设计 , 结构设计 , 框架结构
Title The Design of the Office Building of WangWang Foods Corporation in State of Huai Yin
Abstract
This time designs the topic is a office building of WangWang foods corporation in state of Huai Yin, that building is four layers, adopting the frame structure.
The main process in graduating design is a certain building design project, building design, construction design and the empress period tidies up .For being better to complete the graduate design, I check related design norm and main references.
This design mainly includes the building design and structures to design two parts . The Graduate the request of design according to the civil engineering, carry on the design to the Comprehensive building of state of huai an . Design the process includes the building design part and structures to design the part .The building design requests to the usage of the guest house according to the market, natural condition , the building shape and the building art and indoor arrange etc. the everyone faces to carry on flat surface's arrange to organize with space . The structure design part according to request of the graduation design , include the structure to choose the type, structure arrange , the structure calculation , the construction diagram draw.
Keywords building,the building design,structures to design,the frame structure
工程概况
1.建筑地点:本工程的建筑位于市区。
2.建筑的建筑面积为:3150㎡
3.建筑层数:四层,总高度不大于16m。
4.结构形式:钢筋混凝土框架结构。
5.平面布置:柱网采用 。
6.楼梯采用现浇板式楼梯。
7.屋面排水采用有组织排水。
目 录 38000字
1.引言……………………………………………………………………………1
2.建筑设计说明…………………………………………………………………2
2.1 建筑物的主要组成部分……………………………………………………2
2.2 建筑物的构成系统…………………………………………………………3
2.3 建筑方案……………………………………………………………………3
3.结构设计说明及结构计算……………………………………………………6
3.1结构设计说明……………………………………………………………….6
3.2框架结构的计算简图……………………………………………………… 9
3.3 框架结构的荷载计算……………………………………………………...11
4.框架结构的内力计算和荷载效应组合及侧移验算………………………...22.
4.1楼面板的内力和配筋计算…………………………………………………22
4.2竖向荷载作用下的框架内力计算…………………………………………29
4.3水平地震作用下的框架计算………………………………………………39
4.4框架的荷载效应组合………………………………………………………48
5. 框架结构的配筋计算……………………………………………………….59
5.1框架梁的配筋设计计算……………………………………………………60
5.2框架柱的配筋计算…………………………………………………………65
5.3框架梁柱节点设计…………………………………………………………70
6. 框架结构柱下基础设计…………………………………………………….71
6.1柱下独立基础………………………………………………………………71
7. 框架结构楼梯设计………………………………………………………….78
7.1 楼梯的结构类型选择……………………………………………………...78
7.2 楼梯的荷载项目…………………………………………………………...78
7.3楼梯的设计计算……………………………………………………………81
8.电算部分……………………………………………………………………...86
结 论……………………………………………………………………………..158
致 谢……………………………………………………………………………..159
参 考 文 献……………………………………………………………………..160 |
