带活动挡料销的导板式落料模动画仿真(Proe三维图,仿真视频)
来源:wenku163.com 资料编号:WK16310949 资料等级:★★★★★ %E8%B5%84%E6%96%99%E7%BC%96%E5%8F%B7%EF%BC%9AWK16310949
资料介绍
带活动挡料销的导板式落料模动画仿真(Proe三维图,仿真视频)(论文说明书6500字,Proe三维图,仿真视频动画)
摘 要
本设计题目为带活动挡料销的导板式落料模动画仿真设计,体现了带活动挡料销的冲压类零部件的动画仿真的设计要求、内容及方向,有一定的设计意义。通过对该冲压动画仿真的设计,进一步加强了本人对带活动挡料销的冲压模具的基础知识,为设计更为复杂的动画做好了铺垫和吸取了更深刻的经验。
本设计运用冲压成型工艺及proe动画仿真设计的基础知识,首先分析该冲压模具的结构与性能,最后实现板料冲压成形过程计算机仿真系统设计。在本制作的动画仿真中,采用了活动挡料销进行送料的装置,在送料时不必像固定挡料销那样抬起送料。使用更加方便。
关键词:板料冲压 计算机仿真 系统设计 有限元法
Abstract
The requirement ,content and direction of activities subject to the guide pin block material blanking plate animation simulation module, reflects the activities with sales expected to block parts of the animation category stamping simulation of the design requirements, content and direction of the design of a certain significance. Animation of the simulation through the design of ram, and further strengthened with the activities I expected to block sales of the basics of stamping die, in order to design more complex animation to do a good job of paving the way and draw a more profound experience.
The use of punch forming process design and simulation proe animation design basic knowledge, the first analysis of the stamping die structure and performance, the final realization of sheet metal forming process simulation computer system design. Animation produced in the simulation, the use of marketing activities is expected to block the feeding device, do not feed when the material sold as a fixed block lifted as feed. More convenient to use.
Keywords: Sheet metal stamping, Computer Simulation, System Design,Finite element method
目 录
1、 概述 1
1.1 制作原理 1
1.1.1冲压原理 1
1.1.2 仿真原理
2 、造型设计 2
3 、动画仿真制作流程 5
3.1 对凹模及其他零件的绘制 5
3.2 动画仿真制作流程 12
3.2.1 零件的装配 12
3.2.2 动画制作步骤 17
4 、结束语 24
致谢 25
参考文献 26
|
