深腔阀体注射模设计(含工艺卡片)(含任务书,开题报告,中期检查表,毕业论文说明书9000字,cad图纸6张)
[摘要] 根据塑件的结构特点，提出适合深腔阀体注射成型的模具结构和设计了生产该零件的注射模，并详细描述了模具的工作过程。介绍了注射模的设计方案、设计要点和模具设计时应注意的问题，并对浇注系统的设计计算作了较详细的阐述。
根据注射模的结构和设计要求，该注射模采用了一模四件的模具结构和顶管顶出装置。根据注射模和注射机的关系选择注射机和确定塑件的注射工艺参数。注射模的结构设计包括分型面选择、确定型腔的排列方式、浇注系统设计和成型零件结构设计。成型零件结构设计包括凹模的结构设计、凸模的结构设计。
模具结构的简化，降低了模具成本。经生产验证，模具结构稳定，可靠，效果很好，对类似产品的注射模设计有很好的参考价值。
关键词：深腔阀体注塑模， 注塑模，模具结构，浇注系统。
( The deep valve body injects the mold design)
[ Summary] according to the structure characteristics of the piece of , the molding tool structure that put forward the in keeping with deep valve body's inject to model and designed to produce that spare parts to inject the mold, and detailed described the work process of the molding tool.The problem that should notice when design project, the design important point and molding tools that introduced to inject the mold design, and elaborate towards sprinkling the design calculation of note the system to make to compare detailedly.
According to inject the structure and the design requests of the mold, should inject the mold to adopt a four pieces molding tool structure of mold and crests take care of a device.According to inject the mold and inject the relation choice of the machine to inject the machine and assurance pieces to inject the craft parameter.The structure design that injects the mold includes to divide the type alignment method that faces the choice and makes sure a sprinkle to note the system design and model the spare parts structure design.The design of model the spare parts structure includes the structure design of structure design, convex mold of cave mold.
The simplification of the molding tool structure, lowered the molding tool cost.Through produce the verification, the molding tool structure stability, credibility, effective, to similar the product inject the mold design contain good reference value.
Keyword:The deep valve body notes the mold of , noting the mold of , the molding tool structure, sprinkle to note the system.
|
